| HARDWARE FEATURES |
|
| Standards and Protocols |
• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMP |
| Interface |
• 2 Gigabit SFP WAN/LAN ports
• 1 Gigabit WAN port
• 1 Gigabit LAN/WAN port
• 8 Gigabit LAN ports |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)
EIA/TIA-568 100Ohm STP (Max 100 m)
• 100BASE-TX: UTP category 5, 5e cable (Max 100 m)
EIA/TIA-568 100Ohm STP (Max 100 m)
• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Fan Quantity |
Fanless |
| Button |
Reset Button |
| Power Supply |
53.5VDC/2.43A Adapter |
| PoE Budget |
8 ports PoE+ output, 110 W PoE Budget |
| Flash |
8Mb Nor + 4 GB EMMC |
| DRAM |
1 GB DDR3 |
| Dimensions (WxDxH) |
8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
| Protection |
4 kV surge protection |
| Enclosure |
Steel |
| Mounting |
Desktop/Wall-mount |
| PERFORMANCE |
|
| Concurrent Session |
24,980 |
| New Sessions /Second |
1,900 |
| NAT (Static IP) |
935.5 Mbps / 942.1 Mbps |
| NAT(DHCP) |
940.2 Mbps / 941.7 Mbps |
| NAT(PPPoE) |
913.1 Mbps / 935.2 Mbps |
| NAT (L2TP) |
545.0 Mbps / 912.7 Mbps |
| NAT (PPTP) |
523.0 Mbps / 912.8 Mbps |
| IPsec VPN Throughput (AES256) |
168.5 Mbps |
| OpenVPN |
34 Mbps |
| L2TP VPN Throughput |
• Unencrypted: 845.3 Mbps
• Encrypted: 333.2 Mbps |
| PPTP VPN Throughput |
• Unencrypted: 1012.6 Mbps
• Encrypted: 401.4 Mbps |
| 66 Byte Packet forwarding rate |
154,069 pps / 156,977 pps |
| 1,518 Byte Packet forwarding rate |
81,193 pps / 81,193 pps |
| BASIC FUNCTIONS |
|
| WAN Connection Type |
• Static IP
• Dynamic IP
• PPPoE
• PPTP
• L2TP |
| DHCP |
• DHCP Server
• DHCP Address Reservation
• Multi-IP Interfaces
• Multi-Net DHCP |
| IPv6 |
support |
| VLAN |
802.1Q VLAN |
| IPTV |
IGMP v2/v3 Proxy |
| ADVANCED FUNCTIONS |
|
| Advanced Routing |
• Static Routing
• Policy Routing |
| Bandwidth Control |
IP/Port-based Bandwidth Control |
| Load Balance |
• Intelligent Load Balance
• Application Optimized Routing
• Link Backup
• Online Detection |
| NAT |
• Multi-Net NAT
• Virtual Server
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP |
| Session Limit |
IP-based Session Limit |
