| Dimensions (H x W x D) |
91.4 x 719 x 101 mm |
| Weight |
4.03 kg |
| Package Contents |
- Rally Bar Mini
- Power supply
- AC power cord
- HDMI cable
- USB cable
- Remote control Lens caps for main lens and AI Viewfinder
- User documentation |
| Warranty Information |
Standard: 2-year limited hardware warranty included Extended: Additional one-year extended warranty available at the time of hardware purchase. Contact your reseller for availability. |
| Camera |
| Resolution |
4K, 1440p, 1080p, 900p, 720p, and SD at 30fps |
| Pan |
Motorized ±25° |
| Tilt |
Motorized ±15° |
| Zoom |
4X HD digital zoom |
| Diagonal field of view (dFoV) |
120° |
| Horizontal Field of View |
113° |
| Vertical Field of View |
80.7° |
| Total Room Coverage |
163° Horizontal x 110° Vertical |
| Speakers |
| Woofer |
70 mm |
| Mid-range |
2x / 1.5 in |
| Output |
90 dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at 1 meter |
| Sensitivity |
86+/-2 dB SPL at 1W, 1 meter |
| THD |
1kHz < 2% |
| Speaker Sampling Rate |
48 kHz |
| Microphones |
| Frequency response |
90Hz – 16kHz |
| Sensitivity |
>-36dBFS +/-1 dB @ 1Pa |
| Microphone data rate output |
48 kHz |
| Pickup Range |
4.5 m |
| Beamforming Elements |
Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams |
| Audio processing |
AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector) |
| Noise suppression |
AI filter |
| Add-on Mics |
Supports up to 2 additional Rally Mic Pods |
| RightSense™ Technologies |
| RightLight™ |
Renders natural skin tones for each participant. |
| RightSight |
Maintains persistent room awareness and detects human figures to auto-frame participants. |
| RightSound |
Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo |
| Interfaces |
| HDMI Out |
2 |
| HDMI In |
1 |
| USB 3.0 |
3 x Type A
1 x Type C |
| Network |
10/100/1G Ethernet |
| WiFi |
802.11a/b/g/n/ac (MIMO) |
| External Mic Input |
Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable) |
| Remote Control |
Bluetooth Low Energy |
| Power & Cables |
| Power supply |
Auto-sensing |
| Operating Voltage/Power |
100-240V, 19V, 4.74A |
| Power Supply Dimensions |
127 x 51 x 30 mm |
| DC Cable |
1.5 m |
| AC Cable |
1 m |
| HDMI 1.4 Cable |
2 m |
| USB A to USB C 3.0 Cable |
2.2 m |
| Environmental |
| Operating Temperature |
0 to 40°C |
| Storage Temperature |
-40 to 70 °C |
| Humidity |
10 to 95% |
| BTU/hr |
57 idle, 64 in meeting |
| Security |
| Full Disk Encryption |
AES-128 |
| Data Encryption |
Symmetric Keys, PKI |
| Device Identity |
Protected by device attestation |
| Device Access |
Authenticated using API |
| Key Protection |
Arm TrustZone, RPMP |
| Certifications & Compatibility |
| Certifications |
Zoom™ Certified, Certified for Microsoft Teams as a USB device. Contact the manufacturer for additional information on pending and granted certifications. |
| Compatibility |
Plug and play USB connectivity with virtually any video conferencing application |
| Appliance mode |
Supports compatible video conferencing software in appliance mode (no PC required), including Zoom Rooms Appliances.
Certification pending for Microsoft Teams Rooms on Android and additional video conferencing platforms. |
| General Specifications |
| Built-in Components |
6 beamforming microphones, PTZ camera, 3 speakers, AI Viewfinder, cable management & retention system, table stand, Logitech CollabOS platform |
| Enclosure |
All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference |
| Device Management |
Logitech Sync |
| Displays Supported |
2 |
| Display Resolution |
Up to 4K |
