| Tech Spec |
|
|
Panel
|
|
|
Screen Size
|
30" |
| Panel Technology |
OLED |
| Aspect Ratio |
16:09 |
| Native Resolution |
1,366 × 768 (HD) |
| Brightness |
200 / 600 nit (APL 100% / 25%, without Glass) |
| Contrast Ratio |
200,000 : 1 |
| Dynamic CR |
No |
| Color gamut |
BT709 110% |
| Viewing Angle (H x V) |
178 × 178 |
| Color Depth |
10 bit (R), 1.07 Billion Colors |
| Response Time |
0.1 ms (G to G), 8 ms (MPRT) |
| Refresh Rate |
120 Hz |
| Surface Treatment (Haze) |
Hard Coating 5 H, Haze 3% (Set) |
| Lifetime |
30,000 Hrs (Typ.) |
| Operation Hours (Hours / Days) |
18 / 7 (Moving Content Only) |
| Portrait / Landscape |
Yes / Yes |
| Transparency (Typ.) |
37% (Set) |
| QWP (Quarter Wave Plate) |
No |
|
Mechanical
|
|
| Specification |
|
|
Bezel Color
|
Transparent |
| Bezel Width |
7.9 / 7.9 / 7.9 / 114.7 mm (T/R/L/B) |
| Weight (Head) |
4.2 kg (Head), 2.4 kg (Signage Box) |
| Packed Weight |
10.1 kg |
| Monitor Dimensions (W × H × D) |
680.2 × 496.2 × 15.3 mm (Head), 449.2 × 288.6 × 42.8 mm (Signage Box) |
| Carton Dimensions (W × H × D) |
826 × 593 × 195 mm |
| Protection Glass (Thickness) |
3.0 mm |
| Protection Glass (Tempered / Chemical Strengthening) |
Chemical Strengthening |
| Protection Glass (Anti-Reflective) |
Yes (AR+AF Coating) |
| Protection Glass (Shatter-Proof) |
Yes |
|
Feature
|
|
|
Key Feature
|
Internal Memory (eMMC (16 GB)), Temperature Sensor, webOS7.5, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, RS-232C Sync, Local Network Sync, Video Tag (4), Screen Rotation, Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Status Mailing, Control Manager, PM Mode, Wake on LAN, HDMI-CEC, SI Server Setting |
|
Environment Conditions
|
|
|
Operation Temperature
|
0 to 40 |
| Operation Humidity |
10%-80% |
|
Power
|
|
|
Power Supply
|
AC 100-240 V~, 50/60 Hz |
| Power Type |
Built-in Power |
|
Power Consumption
|
|
|
Typ./Max.
|
45 W (IEC 62087) / 86 W |
| DPM |
0.5 W |
| Power off |
0.5 W |
| BTU (British Thermal Unit) |
154 BTU/Hr (Typ.), 294 BTU/Hr (Max.) |
|
Standard (Certification)
|
|
|
Safety
|
CB / NRTL |
| EMC |
FCC Class "A" / CE / KC |
| ErP |
Yes |
|
Software Compatibility
|
|
|
|
SuperSign CMS, SuperSign Control+, SuperSign Cloud, Mobile CMS, LG ConnectedCare |
|
Connectivity
|
|
|
Input
|
HDMI (HDCP 2.2/1.4), DP (HDCP 1.3), RS-232C, RJ45 (LAN), IR (External IR Receiver), USB2.0 Type A(1), USB2.0 Type A (1,Touch Control Board only) |
| Output |
DP, Audio, Touch USB (USB 2.0 Type B), RS-232C, RJ45 (LAN), IR (Sharing RS-232C) |
|
Language
|
|
|
|
English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Polski, Türkçe, Arabic |
|
Accessory
|
|
|
Basic
|
Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS-232C Gender, MCX / Harness Cables (3 m × 4 ea / 3 m × 2 ea for Connection between Panel and Signage Box), HDMI Cable (3 m), Micro to A Type USB Cable (3 m, for Connection between Touch and Signage Box), A to B Type USB Cable (Touch Out), Screw (M4 × L22, 12 ea / M4 Nut 12 ea / M3 × L5.5 (Silver), M3 × L5.5 (Black) 8 ea / Shield Cover Assy, Rubber Damper 4 ea, Touch Cable Holder 2 ea, MCX Cable Holder 2 ea |
|
Special Feature
|
|
|
Conformal Coating (Power Board)
|
Yes |
|
Touch
|
|
|
Available Object Size for Touch
|
O8 mm ^ |
| Response Time |
100 ms ˇ |
| Accuracy |
2 mm |
| Interface |
USB 2.0 |
| Protection Glass Thickness |
3.0 T (Anti-Glare / Anti-Finger Print) |
| Protection Glass Transmission |
85% (Typ.) |
| Operating System Support |
Windows 10/11 |
| Multi Touch Point |
Max. 10 Points |
